📦 Firmware Format

This document specifies the binary layout of .bin firmware files consumed by SecureLoader. Bootloader and firmware build toolchain authors should refer to this document to ensure compatibility.

Host implementation: src/secure_loader/core/firmware.py.

📋 Table of Contents

  1. Overview
  2. Header Layout (48 B)
  3. Field Semantics
  4. productId Derived Fields
  5. Wire Header (44 B)
  6. Payload
  7. Host Parsing API

🗂️ Overview

A .bin file consists of a 48-byte little-endian header immediately followed by the encrypted payload (the application image). No alignment padding exists between the header and the payload.

graph TB
    subgraph file[".bin file"]
        H["🔢 Header — 48 bytes<br/>little-endian, parsed by host"]
        P["🔒 Encrypted payload — variable length<br/>pageCount × flashPageSize bytes, AES-encrypted"]
    end
    H --> P

🔢 Header Layout (48 B)

Offset Size Type Field
0 4 u32 protocolVersion
4 4 u32 productId (MSB)
8 4 u32 productId (LSB)
12 4 u32 appVersion
16 4 u32 prevAppVersion
20 4 u32 pageCount
24 4 u32 flashPageSize
28 16 bytes IV (Initialization Vector)
44 4 u32 crc32
48 — — start of encrypted payload

All integer fields are unsigned, little-endian.

🔍 Field Semantics

protocolVersion (u32)

Version of the bootloader communication protocol. The host compares this field against the bootloaderVersion reported by the device at connect time. The values must be identical — there is no backwards compatibility; a mismatch prevents flashing. Increment this field only when the wire header format or command semantics change.

productId (u64, stored as two u32)

64-bit product/unit identifier. Stored on disk as two consecutive 32-bit fields (MSB first):

productId = (productId_MSB << 32) | productId_LSB

The host assembles the 64-bit value and compares it against the device's productId from the GET_VERSION response. A mismatch prevents flashing (unless --force is used).

appVersion (u32)

Version of the application image. Displayed in the GUI and CLI for informational purposes. Not validated by the bootloader protocol.

prevAppVersion (u32)

Version of the previous application image. Used by the host to request an older firmware from the HTTP source (fetch_previous). GitHub Releases support is planned — see Roadmap. This field is read by the host but is NOT forwarded to the device — the 44-byte wire header omits it (see Wire Header).

pageCount (u32)

Number of flash pages in the payload. Transmitted to the device inside the wire header — the device uses this value to count received pages and detect when the transfer is complete.

The host drives its send loop by exhausting the payload bytes, not by reading this field. For correctly built firmware, len(payload) / device_page_size == pageCount holds true and the two perspectives agree.

flashPageSize (u32)

Size of one flash page in bytes. The device reports its own flashPageSize in the GET_VERSION response. The host uses the device's reported value for payload segmentation — this header field is informational on the host side. If the device reports 0, the host falls back to 1024 bytes.

IV (16 bytes)

AES Initialization Vector for the encrypted payload. Sent to the device inside the wire header (bytes 28–43). The specific encryption algorithm and key management are outside the scope of this document and are defined by the firmware build toolchain (EncryptBIN).

crc32 (u32)

CRC32 checksum of the encrypted payload. The device verifies this after receiving all pages. If verification fails, the device stays in bootloader mode and the host must retry.

🔑 productId Derived Fields

The 16-hex-digit representation of productId (zero-padded, uppercase) is used to derive two short identifiers:

productId hex:  A A B B C C D D 1 1 2 2 3 3 4 4
index:          0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

licenseId = hex[4:6]    →  "CC"
uniqueId  = hex[12:16]  →  "3344"

These identifiers are used to construct the URL path on the HTTP firmware server:

{base_url}/{licenseId}/{uniqueId}/info.txt      ← plain-text version tag
{base_url}/{licenseId}/{uniqueId}/{version}.bin ← firmware binary

See User Guide — HTTP server requirements for the full fetch workflow.

📡 Wire Header (44 B)

The header transmitted to the device during a firmware update is 44 bytes. prevAppVersion is read from the file and used internally by the host (e.g. to fetch a rollback image), but is not included in the UART payload. This matches the bootloader v1.1+ header_t struct layout exactly.

Compatibility note: the 44-byte wire header requires bootloader v1.1+. A bootloader built from v1.0.0 expects 48 bytes and will stall waiting for the missing 4 bytes. Confirm the target device runs v1.1+ before deploying.

flowchart LR
    subgraph disk["File header — 48 B"]
        A["bytes 0–15<br/>protocolVersion<br/>productId MSB + LSB<br/>appVersion"]
        B["bytes 16–19<br/>prevAppVersion"]
        C["bytes 20–47<br/>pageCount · flashPageSize<br/>IV · crc32"]
    end
    subgraph wire["Wire header — 44 B  (sent to device)"]
        W["START command payload"]
    end
    A -- "copied" --> W
    B -. "host-only\n(not forwarded)" .-> W
    C -- "copied" --> W

Expressed as a slice operation:

wire_header = disk_header[0:16] + disk_header[20:48]
            = protocolVersion + productId (MSB+LSB) + appVersion
              + pageCount + flashPageSize + IV + crc32

This 44-byte block is the payload of the START command.

📦 Payload

The payload immediately follows the 48-byte header at offset 48. It consists of pageCount pages of flashPageSize bytes each:

total_payload_size = pageCount × flashPageSize

If the raw binary has trailing bytes beyond pageCount × flashPageSize, they are silently ignored — the host's split_pages uses integer division so a partial final page is never transmitted.

🐍 Host Parsing API

flowchart LR
    file["📄 .bin file"] --> lf["load_firmware(path)"]
    lf --> hdr["FirmwareHeader\n(frozen dataclass)"]
    lf --> raw["raw bytes"]
    raw --> bdh["build_device_header(raw)\n→ 44 B wire header"]
    raw --> sp["split_pages(payload, page_size)\n→ list[bytes]"]
    hdr --> fields["license_id · unique_id\npayload_size\nformat_product_id() · …"]
from secure_loader.core.firmware import (
    parse_header,          # parse_header(data: bytes) -> FirmwareHeader
    load_firmware,         # load_firmware(path) -> (FirmwareHeader, bytes)
    build_device_header,   # build_device_header(raw: bytes) -> bytes  (44 B, prevAppVersion stripped)
    split_pages,           # split_pages(payload, page_size) -> list[bytes]
)

FirmwareHeader is a frozen dataclass exposing all fields plus helpers: license_id, unique_id, payload_size, format_product_id(), etc.

FirmwareFormatError (subclass of ValueError) is raised when the data is too short or otherwise unparseable.
